ZHUOZHI Smart RGB LED Strip Light - IP65 Waterproof Outdoor Flexible Lighting
Brand: ZHUOZHI | Model: ZZGD-LSL-D88 | Place of Origin: Guangdong, China
Product Overview
This product is a high-quality smart RGB LED strip light manufactured by Zhongshan Zhuozhi Photoelectric Technology Co., Ltd.. Designed for both commercial and residential outdoor use, it features an IP65 waterproof rating, making it resistant to dust and low-pressure water jets from any direction. With a lifespan of up to 50,000 hours and flexible PVC/silicone body, it is ideal for landscape lighting, garden pathways, patio ambiance, and architectural accent lighting.
Technical Specifications
|
Attribute
|
Specification
|
|
Brand Name
|
ZHUOZHI
|
|
Model Number
|
ZZGD-LSL-D88
|
|
Input Voltage
|
DC 5V/12V/24V (Customizable)
|
|
Power
|
7.2W
|
|
Light Source
|
SMD RGB 5050 LED
|
|
IP Rating
|
IP65 (Full Dustproof & Waterproof)
|
|
Control Mode
|
Remote Control (RGB & Dimming)
|
|
Color Temperature (CCT)
|
2700K-6500K (Adjustable) + RGB Colors
|
|
Lifespan
|
> 50,000 Hours
|
|
Working Temperature
|
-40℃ to 50℃
|
|
Material
|
PVC (Imitation Silicone Feel)
|
|
Certification
|
CE Certified
|
Application & Use Cases
-
Outdoor & Garden: Perfect for illuminating pathways, flower beds, and deck areas.
-
Patio & Courtyard: Creates a warm ambiance for outdoor dining and relaxation.
-
Architectural Lighting: Highlights building contours, fences, and walls.
-
Commercial Landscape: Used in hotels, restaurants, and public parks for decorative lighting.
-
Festival & Event Decoration: Waterproof nature makes it suitable for temporary or permanent outdoor events.
Installation & Usage Guide
1. Pre-Installation Checklist
-
Ensure the power is turned OFF before installation.
-
Check if the power supply (adapter) matches the required voltage (e.g., 12V).
-
Plan the layout and measure the required length.
-
Clean the installation surface to ensure it is dry and free of dust/oil.
2. Installation Steps
-
Cutting: Cut the strip only at the marked scissor points (usually every 3 LEDs). Cutting elsewhere will damage that segment.
-
Mounting: Peel off the 3M adhesive backing and firmly press the strip onto the desired surface.
-
Connection: Connect the strip's wires to the corresponding terminals on the power supply (V+ to V+, V- to V-).
-
Controller: Connect the RGB controller between the power supply and the strip for color and mode control.
-
Waterproofing: For extra protection, apply waterproof silicone gel to the cut ends and connection points.
3. Remote Control Operation
The included remote allows you to:
-
Switch between 16 million RGB colors.
-
Adjust brightness levels (Dimmer function).
-
Select dynamic modes (flash, strobe, fade).
-
Save custom color settings.
Buying Guide & Tips
When purchasing LED strip lights, consider the following:
-
IP Rating: For outdoor use, IP65 is the minimum. For areas with heavy rain or potential submersion, consider IP67 or IP68.
-
Voltage: 12V is common for residential use due to safety and lower voltage drop over long distances.
-
LED Chip: 5050 SMD chips are brighter and better for RGB color mixing compared to smaller 3528 chips.
-
Supplier Reputation: On ajfpt.com, look for "Verified" suppliers with transaction history and positive reviews.
-
Sample Order: Consider ordering a sample to test product quality before bulk purchasing.
After-Sales Service & Support
As a manufacturer on ajfpt.com, Zhongshan Zhuozhi Photoelectric Technology Co., Ltd. typically offers:
-
Warranty: 1-year limited warranty on manufacturing defects.
-
Order Protection: ajfpt.com's Trade Assurance protects orders from payment to delivery.
-
Technical Support: Contact the supplier directly via 6688789's messaging system for installation guidance or troubleshooting.
-
Return/Refund: In case of product quality issues, buyers can open a dispute on ajfpt.com to request a refund or replacement.
Frequently Asked Questions (FAQ)
Q1: Can this LED strip be used underwater?
A: No. IP65 rating means it is waterproof against rain and splashing, but it is not designed for submersion. For underwater use (pools, fountains), you need IP68 rated strips.
Q2: What is the maximum length I can connect?
A: The maximum run length depends on the power supply's capacity and the strip's voltage. For a 12V system, it's generally recommended not to exceed 5 meters in a single run without a power booster to avoid voltage drop and dimming.
Q3: How do I fix it if a section of the strip stops lighting up?
A: This is often caused by a damaged connection or a burnt LED. Check for visible breaks or loose solder joints. You can use a soldering iron to repair minor breaks or replace the faulty segment.
Q4: Is the remote control required for operation?
A: The remote is the primary control method for changing colors and modes. However, you can also control the on/off function directly via the power switch. For advanced control (like app control), you would need a different controller model.
Related Search Keywords
rgb led strip light, ip65 waterproof light, outdoor led strip, 5050 smd rgb, zhuozhi led, smart light strip, garden lighting, landscape led strip, remote control led, flexible neon light, wholesale led strip, alibaba verified supplier
Disclaimer: The information provided is based on the product listing from ajfpt.com and general knowledge of LED lighting. Specifications may vary. Please confirm all details with the supplier before purchase.
