UNIKE UNK-SL-2430: High Efficiency Outdoor IP65 LED Solar Street Light
Brand: UNIKE | Model: UNK-SL-2430 | Place of Origin: Guangdong, China
Product Overview
The UNIKE UNK-SL-2430 is an integrated, all-in-one solar street light designed for modern outdoor lighting needs. Featuring a high-efficiency monocrystalline silicon panel and a durable LiFePo4 (Lithium Iron Phosphate) battery, this lamp offers reliable, energy-saving illumination for residential roads, gardens, parks, and pathways. With its smart control system, including remote control and dimming capabilities, it provides a versatile and user-friendly lighting solution. The robust IP65 waterproof rating ensures it can withstand harsh weather conditions, making it a sustainable and cost-effective choice for off-grid lighting.
Technical Specifications
Category
Specification
Light Source
LED (5050SMD, 96pcs)
Luminous Flux
2160 LM ±5%
Lamp Efficiency
180 LM/W ±5%
Color Temperature (CCT)
3000K / 4000K / 5000K / 5700K / 6500K (Optional)
Beam Angle
90° x 130°
Solar Panel
5V / 30W Monocrystalline Silicon
Battery
3.2V / 30AH LiFePo4 Lithium Battery
Charging Time
6 - 9 Hours (with Intelligent Controller)
Lighting Time
Up to 12 hours per night, supports 2-3 rainy days
Working Mode
Timing / Dimming / Light Sensor
Control Method
Remote Control
IP Rating
IP65 (Dust-tight and protected against water jets)
Lifespan
> 50,000 Hours
Warranty
2 Years
Certifications
RoHS, CE, FCC, LVD
Material
Galvanized Plate + PC Lens
Installation
Wall Mount
Usage & Installation Guide
Installation Steps
Location Selection: Choose an open area with no shading to ensure the solar panel receives maximum sunlight throughout the day. Avoid locations near high-tension cables.
Base Preparation: Pour a C20 standard concrete base according to the required dimensions (typically 400x400x800mm for a 4m pole). Ensure the embedded parts and screw rods are properly set.
Battery Placement: Connect the battery terminals firmly and place the battery cabinet in the designated hole. Seal it properly to prevent water seepage.
Solar Panel Mounting: Fix the solar panel to the bracket securely. Test the output voltage (should be ≥18V for a 12V system) before final wiring.
Pole Assembly & Lifting: Assemble the lamp head and pole on the ground. Connect the wires, ensuring correct polarity. Use a hoist to lift the pole upright and secure it to the base. Ensure the solar panel faces south for optimal charging.
Controller Connection: Follow the manual to connect the battery first, then the load (light), and finally the solar panel to the smart controller. Avoid reverse polarity to prevent damage.
Operation & Smart Control
The UNK-SL-2430 features an intelligent controller with multiple working modes accessible via remote control:
Light Sensor Mode: Automatically turns on at dusk and off at dawn.
Timing Mode: Allows setting specific lighting durations (e.g., 3H, 6H).
Dimming Mode: Adjusts brightness levels to save energy during low-traffic hours.
Buyer's Purchase Guide
When selecting a solar street light, consider the following factors to ensure you get a product that meets your specific needs:
Lighting Requirements: Determine the area to be illuminated and choose a model with adequate lumens (lm) and beam angle.
Battery Type: LiFePo4 batteries are recommended for their long lifespan, high safety, and excellent performance across a wide temperature range.
Solar Panel Efficiency: Monocrystalline panels offer higher conversion efficiency compared to polycrystalline, meaning faster charging and better performance in low-light conditions.
Durability & Weatherproofing: Look for an IP65 or higher rating to ensure the fixture is protected against dust and rain. The material (e.g., galvanized steel) should be corrosion-resistant.
Smart Features: Remote control, motion sensors, and dimming capabilities enhance convenience and energy savings.
Warranty & Support: A 2-year warranty is standard for quality products. Check the supplier's reputation and after-sales service policies.
Reviews & Industry Evaluation
Based on manufacturer data and industry standards for 2026, the UNIKE UNK-SL-2430 demonstrates strong performance in key areas:
Energy Efficiency: With a lamp efficacy of 180 lm/W, it ranks among the more efficient solar lights on the market, reducing energy consumption and carbon footprint.
Reliability: The use of high-quality chips and a robust heat dissipation design ensures stable performance and a long lifespan, minimizing maintenance costs.
Cost-Effectiveness: The integrated design and low operational costs make it an economical choice for large-scale municipal or commercial lighting projects.
Note: It is recommended to request samples or consult user reviews on the supplier's page for real-world performance feedback.
Warranty Period: 2 years from the date of purchase.
Warranty Coverage: Covers defects in materials and workmanship under normal use.
Support Services: Offers technical support, installation guidance, and troubleshooting assistance.
Return & Refund Policy: Subject to the platform's (e.g., ajfpt.com) order protection policies, which include money-back guarantees and dispute resolution services.
