DJI PST60 Three-Axis Searchlight Drone Payload
High-Intensity Aerial Illumination for DJI Matrice Series
Product Overview
The DJI PST60 is a high-performance, three-axis stabilized searchlight designed as a payload for DJI Matrice series commercial drones, specifically optimized for compatibility with the Zenmuse H20 and H20T camera systems. This accessory provides powerful illumination for nighttime operations in public safety, search and rescue, industrial inspection, and security applications. It integrates seamlessly with the DJI Pilot 2 application, allowing operators to control lighting modes and brightness directly from the ground control station.
Key Features
- Three-Axis Stabilization: Maintains a steady beam even during drone maneuvers, ensuring consistent illumination on the target area.
- High Lumen Output: Delivers up to 6000 lumens of light flux, providing exceptional visibility in complete darkness.
- Dual Lighting Modes: Features both Constant (steady) and Strobe (burst flash) modes for versatile operational needs.
- PSDK Integration: Built on DJI's Payload SDK, ensuring plug-and-play compatibility with supported DJI flight platforms.
- Camera-Linkage Function: Supports real-time synchronization with the Zenmuse H20/H20T gimbal, automatically tracking the camera's focus point.
- Compact & Lightweight: Weighs approximately 545g, minimizing impact on the drone's flight time and performance.
Technical Specifications
| Attribute | Specification |
|---|---|
| Product Model | PST60 / PST60-400 |
| Compatible Drones | DJI Matrice 350 RTK, Matrice 300 RTK, Matrice 400 |
| Compatible Cameras | DJI Zenmuse H20, Zenmuse H20T, Zenmuse H20N |
| Luminous Flux | 6000 Lm |
| System Power | 60W |
| Weight | Approx. 545g |
| Dimensions | 151mm x 109mm x 155mm |
| Control Interface | DJI SkyPort V2.0 / PSDK |
| Modes | Constant, Strobe (with adjustable brightness) |
| Gimbal Follow | Yes (Supports camera linkage) |
Usage & Application
The PST60 is an essential tool for extending operational capabilities into low-light and nighttime environments. Its primary use cases include:
- Public Safety: Illuminating large areas for law enforcement operations, suspect tracking, and crime scene investigation.
- Search and Rescue (SAR): Providing powerful light to locate missing persons or assess disaster-stricken areas during night missions.
- Industrial Inspection:
- Power Line Inspection: Illuminating towers and cables for detailed visual inspection by H20T's thermal or zoom cameras.
- Infrastructure Inspection: Lighting up bridges, wind turbines, and construction sites for maintenance checks.
- Security & Surveillance: Patrolling large perimeters, warehouses, or critical infrastructure, with the strobe function serving as a visual deterrent.
To operate, users simply mount the searchlight onto the drone's compatible gimbal port (upper or lower position on Matrice 350/300). The device is automatically recognized by the drone, and controls appear within the DJI Pilot 2 app interface, allowing for intuitive adjustment of brightness and mode selection.
Purchasing & Supplier Details
This product is typically available through B2B platforms like ajfpt.com and is manufactured by specialized technology companies in Shenzhen, China, such as Shenzhen Xingshen Future Technology Co., Ltd. These suppliers often act as distributors or wholesalers for drone accessories.
Key Purchase Considerations:
- Minimum Order Quantity (MOQ): Often 10 pieces or more for wholesale orders.
- Lead Time: Typically around 30 days for production and shipping.
- Price Point: Varies based on order volume and supplier, generally ranging from $1,000 to $1,500 per unit.
Order Protection & After-Sales
When purchasing through platforms like ajfpt.com, buyers are protected by services such as:
- Trade Assurance: Protects payments from the initial order to delivery. If product issues arise, ajfpt.com assists in mediation and potential refunds.
- Secure Payment: All transactions are encrypted using SSL and PCI DSS protocols.
- Money-Back Policy: Buyers can claim a refund if the order doesn't ship, is missing, or arrives with product defects.
- Supplier Verification: ajfpt.com verifies manufacturers and provides company profiles, including business licenses and on-time delivery rates.
After-sales support, including warranty claims (typically 1 year) and technical assistance, is provided directly by the supplier. It is recommended to clarify warranty terms before purchasing.
Reviews & Testing
As a specialized industrial accessory, professional reviews are often found in trade publications or user forums focused on commercial drone applications. Key performance aspects highlighted in evaluations include:
- Beam Quality: The 14-degree spotlight angle provides a focused, long-distance beam without significant spillage.
- Stability: The three-axis gimbal effectively counters drone vibrations and movements for a rock-solid light beam.
- Integration: Users report seamless integration with DJI Pilot 2, with reliable camera-follow functionality.
- Battery Impact: While consuming 60W, it has a manageable impact on the flight time of Matrice drones, which are equipped with high-capacity batteries.
